Product Overview
Universal Lighting Technologies Code 188639.05 M1501227CK5EUJ 150 Watt 120-277V Metal Halide Electronic J Stud Mount Ballast
- (1) 150W Ceramic Metal Halide Lamp
- Ansi Code C102,C142, M102,M142
- Voltage : 120-277V +/-10%, 50/60Hz
- Resonance Start
- Active power factor correction
- Microprocessor controlled
- EOL Protection
- DIM: (L) 5.51in (W) 3.62in x (H) 1.57in
- (J) Stub mount (bottom lead exit)
- Universal Order Code 188638.05
- 5-Lead Wires (Black, White, Green,Blue, Red)
- RoHS Compliant
- Spec Sheet
Additional Information
- Energy Efficient
- Greater than 20% increase in efficiency
- Lowers lighting operation costs
- Full Light Output
- Provides same light levels as magnetic ballasts being replaced
- Quiet Operation
- Significantly quieter than magnetic ballasts
- High Frequency Operation
- No lamp flickering
- Light Weight - Low Profile Case
- Simplifies transportation & installation
- Less interference with ballast channel cover during replacement
- Slimline Ballasts Feature Parallel Lamp Operation
- When one lamp fails, other lamp remains lit
- Instant start electronic ballast for long lamp starting cycles and low initial cost
- RoHs Compliant
- UL Type 1 Outdoor
