Product Overview
Universal Triad B332IUNVHPA Universal Voltage 120-277V 50/60hz 3-Lamp Electronic T8 Ballast Operates the Following
- (2-3) F17T8/ECO 24in Fluorescent Lamp
- (2-3) F25T8/ECO 36in Fluorescent Lamp
- (2-3) F32T8/25W 48in Energy Saving F32T8 25W Lamps
- (2-3) F28T8/28W 48in Energy Saving F32T8 28W Lamps
- (2-3) F32T8/WM 48in Energy Saving F32T8 30W Lamps
- (2-3) F32T8 (48in FO32/ECO 32W Standard Lamps)
- (2) FO40 60in Fluorescent T8 Lamp
- (3) F25T12 36in Fluorescent T12 Lamp
- Also Suitable For Equivalent U-Bend Fluorescent T8 Lamps
Additional Information:
Universal Lighting Technology Triad B332IUNVHP-A000I Parallel Instant Start High Performance low profile ballasts with THD<10% offer the convenience of universal input voltage (108 - 305 volts) ensuring you have the right voltage ballast, and a low profile design for greater flexibility in light fixture design.Will easily retrofit any T12 into a T8 fixture Also meets UL Listed for wet or damp locations & approved by the NEMA Premium Electronic Ballast program
Product Details
- High performance electronic ballast for all general fluorescent applications
- Instant start electronic ballast for long lamp starting cycles and low initial cost
- Multi-Voltage Technology handles voltage from 120 to 277V
- Light-weight, Low Profile Housing (Dim:9.5”L x 1.7”W x 1.18”H)
- Parallel Circuitry: keeps remaining lamps lit if one or more go out
- Line Voltage: 108vac - 305vac, 50/60Hz
- Manufactured in North America
- Meets ANSI Standard C82.11-1993
- Normal Ballast Factor < 10% THD
- Sound Rating A (20-24 decibels)
- Parallel Instant Start
- RoHs Compliant
- UL Type 1 Outdoor
Cross Reference:
- GE-332-MV-N
- Sylvania QTP3X32T8/UNV ISN-SC
- Philips Advance ICN-3P32-N
- Howard EP3/32IS/120-277
- Halco Prolume EP332IS/MV/SL
- Keystone KTEB-332LBF-UV-TP-PIC
