Philips Smartmate SMARTMATE ICF2S70M4LD 120V/277V  Programmed Start Electronic CFTR70W/GX24Q Ballast Will Operate

• (1 or 2 ) CFTR70W/GX24q Or (GE F70QBX/4P, Sylvania CF70DT/E)

Product Details

• Doesn't Include The Kit
• Rated Dual Voltage 120-277V 50/60Hz

• Dual-entry Connector allows ballast to be used with side or bottom exit leads
• Contains auto restart circuitry in order to restart lamps without resetting power.
• Ballast shall be Programmed Start except for ballasts

• With -QS suffix, which shall be Rapid Start.
• Lamp End-Of-Life (EOL) Protection Circuit
• Color-coded, poke-in terminals
• Class A sound rating.

General Information Lamp Type CFTR70W/GX24Q Number of Lamps 2 piece/unit Ballast Type Electronic Fluorescent Base Model ICF2S70M4LD Suitable For Outdoor Use Yes Automatic Restart Yes Operating and Electrical Input Voltage 120 to 277 V Input Frequency 50 to 60 Hz Max THD 10 % Starting Method Programmed Start Lamp Current Crest Factor (Nom) 1.5 Ignition Time (Nom) 1.5 s Ballast Factor (Nom) 1 Power Factor (Nom) 0.98 Input Current (Operating) (Max) 1.30 A Input Current (Operating) (Min) 0.56 A Input Power (Nom) 156-152 W Rated Lamp Watts 70 W
