Product Overview
Sylvania Lighting #51899 Professional Series Quicktronic Prostart QTP2X26CFUNVSPEM Programmed Start Electronic Compact Fluorescent Ballast
Operates the Following Fluorescent Lamps:
- (1 or 2) CFQ26W/G24q
- (1 or 2) CFTR26W/GX24q
- (1-2) FT24W/2G11
- (1-2) FT18W/2G11
- (1-2) FT24W/2G11
- (1) CFTR32W/GX24q
- (1) CFTR42W/GX24q
- (1) CFS28W/GR10q,
- (1) CFS38W/GR10q,
- (1-2) FPC22/T5 (FC9T5 22W) Or (1) FPC40/T5 (FC12T5 40W)
- Dual Entry (Bottom & Side Color Coded Entry Connectors)
- Doesn't Include Ballast Kit *Mounting Plate,Wire,Tools*
Additional Information:
- Remote Mounting up to 15 feet for one lamp and up to 6 feet for two lamps
- Normal Power Factor > 98%
- Starting Method Programmed Rapid Start
- UL Listed Class P, Type 1 Outdoor
- Ground ballast case
- Install in accordance with National Electric Codes
- Complies with FCC 47 CFR Part 18, Non-Consumer
- ANSI 62.41 Cat. A Transient Protection
- Class A Sound Rating.
- Voltage Range: ±10% of 120-277V Rated line (108-305V)
- Minimum Starting Temperature: -4F/-20C.
- CSA certified. ANSI C82.11 where applicable. N
- No PCB (Polychlorinated Biphenyl)
- 75°C Max. Case Temp./80°C Max Case Temp.
