Product Overview
Sylvania Quicktronic Professional Series QTP 2x32T8/UNV PSX-TC 2-Lamp Programmed Rapid Start T8 Ballast
Operates the Following Fluorescent Lamps:
- (1-2) FO17 24in Fluorescent Lamp
- (1-2) FO25 36in Fluorescent Lamp
- (1-2) FO32/25W 48in Energy Saving F32T8 25W Lamps
- (1-2) FO32/28W 48in Energy Saving F32T8 28W Lamps
- (2) FO30/SS (48in Energy Saving F32T8 30W Advantage Lamps)
- (1-2) F32T8 (48in FO32/ECO 32W Standard Lamps)
- (1-2) FBO16,FBO24, FBO29/SS, FBO30/SS, FBO31,FBO32 U-Bend Lamps
- (1) FO40 60in Fluorescent T8 Lamp
- Ballast Factor 0.71
Additional Information:
- 70C Max Case Temperature
- UL Listed Class P, Type 1 Outdoor
- Ground ballast case
- Lamp holder must be shorted per diagram
- Install in accordance with National Electric Codes
- Complies with FCC 47 CFR Part 18, Non-Consumer
- ANSI 62.41 Cat. A Transient Protection
- Class A Sound Rating.
- Input Frequency: 50/60Hz.
- Complies with UL935 requirements for "Type CC" rating
- Minimum starting temperature: 60 F / 16 C with SS lamps
- Minimum starting temperature: -20 F / -29 C
- CSA certified.
- ANSI C82.11 where applicable.
- NO PCB (Polychlorinated Biphenyl)
- Remote mounting up to 20 feet Lamp Striation Control (LSC) may minimize
- Or eliminate lamp striations which can occur in T8 energy savings lamps.
- Small Can Enclosure Design (Dim:9.47”L x 1.69”W x 1.18”H)
- Minimum starting temperature: -20 F / -29 C
- Complies with FCC 47 CFR Part 18, Non-Consumer
- Normal Ballast Factor < 10% THD
- Dual Voltage 120-277V 50/60Hz
- Circuit Type Parallel
- Meet NEMA Premium Electronic M Ballast Program Requirements and qualify for utility incentives
- Deliver 30-60% energy savings when D compared to F34T12 magnetically ballasted systems
- Offer up to 6% (2-5 Watt) energy O savings over standard electronic ballasts
- Achieve over A 100 (LPW) with OCTRON® 800 XP® SUPERSAVER® lamps
- Available in: A – Instant Start and PROStart® (Programmed Rapid Start)
- Bi-level QUICKSTEP® and POWERSENSE® Dimming models
- Excellent for The Most Stringent energy codes and sustainability focused projects
