Product Overview
Sylvania Quicktronic Prostart High Ambient QHE4x54T5HO/UNV PSN-HT 4-Lamp 54W Ballast
Operates the Following Lamps:
- (3-4) F54T5/HO (F54T5HO/Alto,FP54HO/ECO,FQ 54W,F54WT5/ECO)
- (3-4) FT55DL/2G11(PL-L 55W/4P, FT55DL/ECO, Dulux L 55W/4P)
- (3-4) FPC55 (FC12T5/HO 55W HO Circular T5 4-Pin)
- (3-4) L58W T8 Fluorescent Lamps
Additional Information:
- Lead Wires included
- Sold 10/Case
- High Efficiency Systems over 90% efficient
- 90°C maximum case Temp
- 100% Ballast Factor
- Quicksense ballast technology (end-of-lamp-life sensing)
- PROStart programmed rapid start
- UL type CC rated U •
- 20°F (-29C) MIN.Starting Temp
- Universal Voltage: 120 - 277 vac, ±10%, 50/60Hz
- Quicksense ballast technology (end-of-lamp-life sensing)
- ProStart programmed rapid start
- UL type CC rated
- 0°F (-18°C) Starting
- Operates at >40 kHz to reduce potential interference with infrared control systems
- Low harmonic distortion
- UL, CSA, FCC
- RoHS compliant
- Lead-free solder and manufacturing process
- Over 100,000 switching cycles for occupancy sensor and building control systems applications
- Light-weight, Low Profile Housing
- (16.73"L x 1.18"W x 1.0"H)
- Manufactured in North America
- Meets ANSI Standard C82.11-1993
- Sound Rating A (20-24 decibels)
- UL Type 1 Outdoor
Sylvania Quicktronic High Ambient (HT) PHO is specifically designed for those applications
where the ballast is subjected to higher ambient temperatures,
with full lumen output and optimal system performance.
