Universal M2012-CK-6EU-F

Universal 20W  Metal Halide M156 1-Lamp Electronic 120V Mini Square Case Ballast

Operates the Following Fluorescent Lamps:

• (1) 20W Ceramic Metal Halide Lamp
• Ansi Code M156/C156
• Voltage : 120V, +/-10%, 50/60Hz
• Microprocessor controlled

• DIM: (L) 3.74in (W) 2.98in x (H) 1.21in
• Feet mount (Side lead exit)
• Universal Order Code 188151
• 5-Lead Wires( Black, White, Green,Blue, Red)
• RoHS Compliant
• Spec Sheet


Additional Information

• Energy Efficient
• Greater than 20% increase in efficiency
• Lowers lighting operation costs

• Full Light Output
• Provides same light levels as magnetic ballasts being replaced
• Quiet Operation

• Significantly quieter than magnetic ballasts
• High Frequency Operation
• No lamp flickering
• Light Weight - Low Profile Case
• Simplifies transportation & installation
• Less interference with ballast channel cover during replacement
• Slimline Ballasts Feature Parallel Lamp Operation
• When one lamp fails, other lamp remains lit
• Instant start electronic ballast for long lamp starting cycles and low initial cost

• RoHs Compliant

• UL Type 1 Outdoor


Cross Reference

• Aromat M2012CK-6EU-F

• Vossloh Schwabe M2012CK-6EU-F
