Product Overview
Osram 4-pin Dulux L 24 Watt Lumilux Cool White 2G11 base Double Tube Compact Fluorescent Lamp
Product Details
- Order Information Dulux L Lumilux 24 W/840 2G11 10/CS 1/SKU
- Average Rated Life 20,000hrs
- Base 2G11 (4-Pin)
- Long Twin Tube Bulb (T5)
- Color Rendering Index (CRI) 80...89
- Family Brand Name Dulux L
- Industry Standards ANSI C78.901 - 2001
- Initial Lumens at 25C 1800
- Maximum Overall Length - MOL 317mm
- Diameter 0.630in
- Diameter 16in
- Nominal Wattage 24W
- Color Temperature/CCT 3000K4000k (840) Lumilux Cool White
- Could Be Used With Magnetic, Electronic, Or Dimming Ballast
- Spec Sheet
Cross Reference
- GE F27BXSPX30RS
- Philips PL-L 24W/830/4P
- Osram Dulux L 24W/830
- Ushio CF-L248SE/830
- FT24W/3000K/2G11
Replacement 24W 2G11 Ballast
- GE #47534 B224PUNV-C
- Sylvania QTP2X26CF/UNV/ DM
- Universal Triad C2642UNVME
- Universal Lighting B224PUNV
| Approximate initial lumens after 100 hours operation. Minimum starting temperature is a function of the ballast; consult the ballast manufacturer. There is a NEMA supported, industry issue where T2, T4, and T5 fluorescent and compact fluorescent lamps operated on high frequency ballasts may experience an abnormal end-of-life phenomenon. This end-of-life phenomenon can resultin one or both of the following: 1. Bulb wall cracking near the lamp base. 2. The lamp can overheat in the base area and possibly melt the base and socket. NEMA recommends that high frequency compact fluorescent ballasts have an end-of-life shutdown circuit which will safely and reliably shut down the system in the rare event of an abnormal end-of-life failure mode described above. The final requirements of this system are yet to be defined by ANSI. For additional information refer to NEMA papers on their WEBSITE at www.NEMA.org. The life ratings of fluorescent lamps are based on 3 hr. burning cycles under specified conditions and with ballast meeting ANSI specifications. If burning cycle is increased, there will be a corresponding increase in the average hours life. Rule of Thumb for Compact Fluorescent Lamps: Divide wattage of incandescent lamp by 4 to determine approximate wattage of compact fluorescent lamp that will provide similar light output. |
