Product Overview
GE LED Type B LED21ED17/750/HAZ 21 Watt 120-277V Daylight ED17 LED Lamp for Hazardous Locations
Product Overview
The LED21ED17/750/HAZ Part Number 93134834 is a high-performance LED retrofit lamp designed for hazardous locations. It offers 3,000 lumens of bright, energy-efficient light, making it an ideal replacement for traditional HID lamps. With a 50,000-hour rated life (L70), this lamp reduces maintenance costs and provides long-lasting reliability in demanding environments.
Technical Specifications
- Wattage: 21W
- Dim: 5.4in x 2.6in
- Voltage: 120-277V
- Color Temperature: 5000K (Daylight)
- Base Type: E26/E39 (Med or Mogul base)
- Luminous Flux: 3,000 lumens
- Rated Life: 50,000 hours (L70)
- Operating Temp -20 to 65 °C
- Certifications: UL-certified for hazardous locations, DLC qualified.
- Dimmable Do not use with phase-cut dimmers. Dimming functions only with external Variac control devices.
Key Features
- High Lumen Output: 3,000 lumens for superior illumination.
- Energy Efficiency: Replaces 50W HID lamps while consuming only 21W.
- Hazardous Location Certified: Approved for use in Class I, Division 2, Groups A, B, C, D and Class II, Division 1 & 2, Groups E, F, G environments.
- Durable Design: Built to withstand harsh conditions with a damp location rating.
- Temperature Code: T4A (120°C max), ensuring safe operation in high-temperature environments.
- E39 Socket Adapter: Included for easy installation in mogul base fixtures.
Applications
- Industrial Facilities: Petrochemical plants, drilling rigs, and manufacturing sites.
- Hazardous Environments: Areas with flammable gases, vapors, or combustible dust.
- Outdoor Lighting: Parking lots, storage yards, and other outdoor damp locations.
Compliance and Safety
- UL 1993 Certified: Meets environmental requirements for LED lamps.
- NEMA LL 10-2020 Compliant: Exceeds light output equivalency standards for HID replacement.
- Hazardous Location Approval: Suitable for use in environments with flammable gases, vapors, and combustible dust.
