Product Overview
Low Voltage Brass Single-piece compression molded fiberglass reinforced polyester composite
• Pre-wired with 36", 18-2, UL listed, 105°C, SPT-2 lead wire
• Clear tempered glass lens for shock and heat resistance
• Rated 12 Volt
• Ceramic GU5.3 bi-pin socket with nickel contacts
• MR16 – 57W maximum
• 415/16" X 43/4"
• Specs
Housing:
• Single-piece compression molded fiberglass reinforced
polyester composite
Cover:
• Fixture includes a trim ring cover
• Constructed of Composite, Antique Brass, Brass, or Stainless Steel
• Composite, Antique Brass, and Stainless Steel fixtures are mounted with five stainless steel screws
• Brass fixture is mounted with five brass screws
• Silicone o-ring provides a watertight seal
• IP65 rated
Cover Finish:
• Available in Composite Black, Antique Brass, Brass, or
Stainless Steel finish
• Brass is a natural finish that ages gracefully as patina
develops over time
• Antique Brass finish is natural brass with an electrostatic
coating that is hand polished and rubbed for an elegant,
aged brass appearance
• Composite fixtures feature a natural black finish
Lens:
• Clear tempered glass lens for shock and heat resistance
Socket:
• Ceramic GU5.3 bi-pin socket with nickel contacts
• Stainless steel retention clip ensures secure lamp seating
and protects the lamp from shock and vibration
• Heat resistant Teflon-coated wire leads
• UL Listed
Aiming:
• Adjustable lamp bracket provides +/- 15 degrees of tilt
from vertical
Lamp:
• MR16 – 57W maximum
• Assortment of LED, energy saving and extended life lamps
are available
Electrical:
• 12 Volt system
• Pre-wired with 36", 18-2, UL listed, 105°C, SPT-1 lead wire
• Two King® DryConn™ waterproof connectors that enable
easy wiring are included with the fixture
Certifications:
• ETL Listed to UL Standard 1838 and CSA C22.2 No. 12-1982
Fasteners:
• All fasteners are corrosion-resistant stainless steel
Warranty:
• Lifetime warranty on Stainless Steel
• Antique Brass, Brass, and Composite are warranted against
defects in materials and workmanship for 10 years from the
date of shipment
